2-3/8" x 5/8" V-Groove Steel Wheel - 220 Lbs Capacity

Part # H306Y-60

Availablity: Usually ships in 24-48 hours
+


2-3/8" x 5/8" (60mm x 24mm) V-Groove Solid Steel Wheel - Part # H306Y-60

This 60mm x 24mm V-groove wheel is made out of solid steel, and has a lightly oiled surface giving it a polished, clean finish. The solid steel material allows for exceptionally low rolling resistance, outstanding wear resistance, and extremely high static and dynamic load capacity.

V groove wheels are designed to guide equipment by rolling on inverted angle iron track. Please note if more than one track is being used, it is critical for the tracks to be parallel, strait and level. Otherwise the wheels could bind or derail. Recommend track tolerance is 1/64" per 20 Feet.

Specifications:

Capacity (lbs.): 220 Hub Length: 24mm (.945")
Wheel Diameter: 60mm (2.362") Groove Width: 14mm (.551")
Tread Width: 24mm (.944") Groove Depth: 8.89mm (.35")
Wheel Type: Solid Steel V-Groove Durometer: 190 - 230 HB
Bearing ID: 8mm Temp Range: -13˚F to 180˚F
Bearing Type Sealed Ball Bearings Weight: 0.63 Lbs
