5" x 2" Cast Iron V-Groove Wheel Rigid Brake Caster - 900 Lbs Capacity

$31.51

Part # 146VIRB520RB

Availablity: Usually ships in 24-48 hours

PRODUCT DETAILS

5" x 2" Cast Iron V-Groove Wheel Rigid Brake Caster - Part # 146VIRB520RB

V groove wheels are designed to guide equipment by rolling on inverted angle iron track, however, they can also operate while not on a track thanks to the tread on either side of the v-groove. The cast iron wheel offers a strong, resilient, cost effective solution for heavy loads. If more capacity is needed, check out the heavier duty ductile steel & forged steel wheels.

Specifications:

Load Capacity (lbs.): 900	Link to Matching Swivel Brake Caster: 146VIRB520SB Link to Matching Swivel Caster with Total Locking Brake: 146VIRB520SBTL
Wheel Diameter: 5"	Wheel Durometer: Brinell 145
Tread Width: 2"	Wheel Color: Black
Wheel Type: Cast Iron V-Groove	Swivel or Rigid Caster: Rigid
Wheel Bearing Type: See Options	Swivel Radius: N/A
Overall Height: 6-1/2"	Swivel Construction: N/A
Temp Range: - 45°F to 600°F	Mounting Plate: 4" x 4-1/2"
V-Groove Width: 7/8"	Bolt Hole Pattern: 2-5/8" x 3-5/8" slotted to 3"x 3"
V-Groove Depth: 7/16"	Mounting Bolt Size: 3/8" or Smaller
Link to Replacement Wheel: LVG520	Weight: 6.18 Lbs
